USB Interface
• Kecepatan: 12 Mbps, 480 Mbps
• Konektor USB: USB Type B
• Standar USB: USB 1.1/2.0 compliant

Antarmuka Serial
• Jumlah port:
• UPort 1200: 2 port
• UPort 1400: 4 port
• UPort 1600-8: 8 port
• UPort 1600-16: 16 port
• Konektor serial: DB9 male
• Baudrate: 50 bps hingga 921.6 kbps
• Data bits: 5, 6, 7, 8
• Stop bits: 1, 1.5, 2
• Parity: None, Even, Odd, Space, Mark
• Flow control:
• None
• RTS/CTS
• XON/XOFF
• Isolasi: 2 kV (khusus model I)
• Standar serial:
• UPort 1410 / 1610-8 / 1610-16: RS-232
• UPort 1250 / 1250I / 1450 / 1650-8 / 1650-16: RS-232, RS-422, RS-485

Sinyal Serial
• RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
• RS-422: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-2w: Data+, Data-, GND

Dukungan Driver & Software
• Windows drivers:
• Windows 11, 10, 8.1, 8, 7, Vista, XP, ME, 98, 95
• Windows Server 2022, 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003, 2000, NT
• Linux drivers:
• Kernel 6.x, 5.x, 4.x, 3.x, 2.6.x, 2.4.x
• Mac drivers:
• macOS 10.12 hingga 10.15, 11.x
• Virtual machine support:
• VMware Fusion (Windows di macOS 10.12 hingga 11.x)
• VMWare ESXi (Linux kernel 4)
• Parallels Desktop (Windows di macOS 10.12 hingga 11.x)
• Arm®-based platform support:
• Linux kernel 5.x / 4.x
• Android API:
• Android 3.1.x dan yang lebih baru

Parameter Daya
• Tegangan masukan:
• UPort 1250 / 1410 / 1450: 5 VDC
• UPort 1250I / 1400 / 1600-8: 12 hingga 48 VDC
• UPort 1600-16: 100 hingga 240 VAC
• Arus masukan:
• UPort 1250: 360 mA @ 5 VDC
• UPort 1250I: 200 mA @ 12 VDC
• UPort 1410 / 1450: 260 mA @ 12 VDC
• UPort 1450I: 360 mA @ 12 VDC
• UPort 1610-8 / 1650-8: 580 mA @ 12 VDC
• UPort 1600-16: 220 mA @ 100 VAC

Karakteristik Fisik
• Housing: Metal
• Dimensi:
• UPort 1250 / 1250I: 77 × 26 × 111 mm (3.03 × 1.02 × 4.37 in)
• UPort 1410 / 1450 / 1450I: 204 × 30 × 125 mm (8.03 × 1.18 × 4.92 in)
• UPort 1610-8 / 1650-8: 204 × 44 × 125 mm (8.03 × 1.73 × 4.92 in)
• UPort 1610-16 / 1650-16: 440 × 45.5 × 198.1 mm (17.32 × 1.79 × 7.80 in)
• Berat:
• UPort 1250 / 1250I: 180 g (0.40 lb)
• UPort 1410 / 1450 / 1450I: 720 g (1.59 lb)
• UPort 1610-8 / 1650-8: 835 g (1.84 lb)
• UPort 1610-16 / 1650-16: 2,475 g (5.45 lb)

Batasan Lingkungan
• Suhu operasi:
• UPort 1200: 0 hingga 60°C (32 hingga 140°F)
• UPort 1400 / 1600-8 / 1600-16: 0 hingga 55°C (32 hingga 131°F)
• Suhu penyimpanan (termasuk kemasan): −20 hingga 75°C (−4 hingga 167°F)
• Kelembapan relatif: 5–95% (tanpa kondensasi)

Standar dan Sertifikasi
• EMC: EN 55032/35
• EMI: CISPR 32, FCC Part 15B Class A
• EMS:
• IEC 61000-4-2 ESD: Contact 4 kV; Air 8 kV
• IEC 61000-4-3 RS: 80 MHz hingga 1 GHz: 3 V/m
• IEC 61000-4-4 EFT: Power 1 kV
• IEC 61000-4-5 Surge: Power 1 kV
• IEC 61000-4-6 CS: 150 kHz hingga 80 MHz: 3 V/m
• IEC 61000-4-8 PFMF
• Keamanan:
• UPort 1200 / 1600-16: UL 60950-1
• UPort 1400 / 1600-8: UL/IEC 62368-1

Deklarasi Lingkungan
• Green Product: RoHS, CRoHS, WEEE

MTBF
• UPort 1250 / 1250I: 563,179 jam
• UPort 1410: 394,441 jam
• UPort 1450 / 1450I: 546,770 jam
• UPort 1610-8: 208,413 jam
• UPort 1650-8: 186,567 jam
• UPort 1610-16: 138,704 jam
• UPort 1650-16: 120,001 jam
• Standar pengujian:
• UPort 1250 / 1250I / 1410 / 1450 / 1450I: Telcordia (Bellcore) Standard
• UPort 1610-8 / 1650-8 / 1610-16 / 1650-16: MIL-HDBK-217F

Garansi
• 5 tahun
