USB Interface
• Kecepatan: 12 Mbps
• Konektor USB:
• USB Type A: UPort 1110 / 1130 / 1130I / 1150
• USB Type B: UPort 1150I
• Standar USB:
• USB 2.0 compatible
• USB 1.0/1.1 compliant

Antarmuka Serial
• Jumlah port: 1
• Konektor: DB9 male
• Baudrate: 50 bps hingga 921.6 kbps
• Data bits: 5, 6, 7, 8
• Stop bits: 1, 1.5, 2
• Parity: None, Even, Odd, Space, Mark
• Flow control:
• None
• RTS/CTS
• XON/XOFF
• Isolasi: 2 kV (khusus model “I”)
• Standar serial:
• RS-232: UPort 1110
• RS-422/485: UPort 1130 / 1130I
• RS-232/422/485: UPort 1150 / 1150I

Sinyal Serial
• RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
• RS-422: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-2w: Data+, Data-, GND

Dukungan Driver & Software
• Windows drivers:
• Windows 11, 10, 8.1, 8, 7, Vista, ME, XP
• Windows Server 2022, 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003, 2000, NT
• Linux drivers:
• Kernel 6.x, 5.x, 4.x, 3.x, 2.6.x, 2.4.x
• Mac drivers:
• macOS 10.12 hingga 10.15
• Arm®-based platform support:
• Linux kernel 6.x, 5.x, 4.x
• Windows 11
• Virtual machine support:
• VMware Fusion (Windows di macOS 10.12–10.15)
• VMWare ESXi (Windows 7–10, Windows Server 2008 R2–2019)
• VMWare ESXi (Linux kernel 5 dan 4)
• Parallels Desktop (Windows di macOS 10.12–10.15)
• Android API:
• Android 3.1.x dan yang lebih baru

Parameter Daya
• Tegangan masukan: 5 VDC
• Arus masukan:
• UPort 1110: 30 mA
• UPort 1130: 60 mA
• UPort 1130I: 65 mA
• UPort 1150: 77 mA
• UPort 1150I: 260 mA

Karakteristik Fisik
• Housing:
• UPort 1110/1130/1130I/1150: ABS + Polycarbonate
• UPort 1150I: Metal
• Dimensi:
• UPort 1110/1130/1130I/1150: 37.5 × 20.5 × 60 mm (1.48 × 0.81 × 2.36 in)
• UPort 1150I: 52 × 80 × 22 mm (2.05 × 3.15 × 0.87 in)
• Berat:
• UPort 1110/1130/1130I/1150: 65 g (0.14 lb)
• UPort 1150I: 75 g (0.16 lb)

Batasan Lingkungan
• Suhu operasi: 0 hingga 55°C (32 hingga 131°F)
• Suhu penyimpanan (termasuk kemasan): −20 hingga 70°C (−4 hingga 158°F)
• Kelembapan relatif: 5–95% (tanpa kondensasi)

Standar dan Sertifikasi
• EMC: EN 55032/35
• EMI: CISPR 32, FCC Part 15B Class 1
• EMS:
• IEC 61000-4-2 ESD: Contact 4 kV; Air 8 kV
• IEC 61000-4-3 RS: 80 MHz hingga 1 GHz: 3 V/m
• IEC 61000-4-4 EFT: Power 1 kV; Signal 0.5 kV
• IEC 61000-4-5 Surge: Power 2 kV
• IEC 61000-4-6 CS: 150 kHz hingga 80 MHz: 3 V/m
• IEC 61000-4-8 PFMF
• Keamanan: UL 60950-1 (UPort 1150I)

Deklarasi Lingkungan
• Green Product: RoHS, CRoHS, WEEE

MTBF
• Waktu: 1,949,025 jam

Garansi
• 5 tahun
