CA5X-01 CONTACT AUX
CA5X-01 is a 1-pole front mounted auxiliary contact block equipped with screw terminals and can be fitted on AX06…150 contactors and NX contactor relays. CA5X-01 is available with 1 N.C. instantaneous contacts for standard industrial environments.
Download Catalog Click Here!
| MAIN SPECIFICATION | |
|---|---|
| ABB Global ID | ABB1SBN019010R1001 |
| Business Area (Master Data) Name | Electrification |
| Catalog Description | CA5X-01 Auxiliary contact block |
| Division (Master Data) Name | Smart Power |
| EAN | 3471522387912 |
| Rated Insulation Voltage (Ui) | acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 volt |
| SKU ID | 1SBN019010R1001 |
| TECHNICAL | |
| Product Name | Auxiliary Contact Block |
| Rated Operational Current AC-15 (Ie) | (220 / 240 V) 4 A (24 / 127 V) 6 A (690 V) 2 A (380 / 440 V) 3 A |
| Rated Short-time Withstand Current (Icw) | for 0.1 s 140 A for 1 s 100 A |
| Terminal Type | Screw Terminals |
| ORDERING | |
| Minimum Order Quantity | 10 piece |
| Selling Unit Of Measure | piece |
| CLASSIFICATIONS | |
| CN8 | 8503 00 99 |
| E-Number (Finland) | 3708078 |
| ETIM 6 | EC000041 – Auxiliary contact block |
| ETIM 7 | EC000041 – Auxiliary contact block |
| IDEA Granular Category Code (IGCC) | 4743 >> Auxiliary contact block |
| Object Classification Code | K |
| UNSPSC | 39121522 |
| WEEE B2C / B2B | Business To Business |
| OTHER | |
| Number Of Auxiliary Contacts NC | 1 |
| Product Net Width | 10 |
| Rated Operational Voltage | Auxiliary Circuit 690 V Main Circuit 690 V |
| Suitable For | AX06 AX09 AX12 AX18 AX25 AX32 AX40 AX50 AX65 AX80 AX95 AX115 AX150 NX |
