Cellular Interface
Cellular Standards
- LTE CAT-4, UMTS,HSPA, EDGE, GSM, GPRS
Band Options (US)
- LTE Band B2 (1900 MHz) / LTE Band B4 (AWS MHz) / LTE Band B5 (850 MHz) / LTE Band B13 (700 MHz) / LTE Band B17 (700 MHz) / LTE Band B25 (1900 MHz)
UMTS/HSPA 2100 MHz / 1900 MHz / AWS MHz / 850 MHz / 900 MHz
Universal quad-band GSM/GPRS/EDGE 850 MHz / 900 MHz / 1800 MHz / 1900 MHz
- LTE Band B2 (1900 MHz) / LTE Band B4 (AWS MHz) / LTE Band B5 (850 MHz) / LTE Band B13 (700 MHz) / LTE Band B17 (700 MHz) / LTE Band B25 (1900 MHz)
Band Options (EU)
- LTE Band 20 (800 MHz) / LTE Band 5 (850 MHz) / LTE Band 8 (900 MHz) / LTE Band 3 (1800 MHz) / LTE Band 1 (2100 MHz) / LTE Band 7 (2600 MHz)
UMTS/HSPA 5 (850 MHz) / LTE Band 8 (900 MHz)
- LTE Band 20 (800 MHz) / LTE Band 5 (850 MHz) / LTE Band 8 (900 MHz) / LTE Band 3 (1800 MHz) / LTE Band 1 (2100 MHz) / LTE Band 7 (2600 MHz)
Band Option (APAC)
- LTE Band 19 (850 MHz) / LTE Band 6 (850 MHz) / LTE Band 6 (850 MHz) / LTE Band 8 (900 MHz) / LTE Band 3 (1800 MHz) / LTE Band 1 (2100 MHz)
UMTS/HSPA 850 MHz / 850 MHz / 900 MHz / 2100 MHz
- LTE Band 19 (850 MHz) / LTE Band 6 (850 MHz) / LTE Band 6 (850 MHz) / LTE Band 8 (900 MHz) / LTE Band 3 (1800 MHz) / LTE Band 1 (2100 MHz)
LTE Data Rate
- 10 MHz bandwidth: 150 Mbps DL, 50 Mbps UL
Antenna Connectors
- 2 SMA connector(s)
Physical Characteristics
Weight
- Packaged: 700 g (1.54 lb)
Standards and Certifications
EMI
- CISPR 32, FCC Part 15B Class A
EMC
- EN 61000-6-2/-6-4, EN301489-1-52, EN 55032/35
Radio
- RED, TELEC
MTBF
Time
- 932,351 hrs
MRC Server Software
Amazon AWS EC2
- Supports Amazon AWS EC2 service (can be downloaded from AWS Marketplace)
Licensing
- Apply for an MRC Server License from Moxa’s channels before activating your software portal
MRC Client Software
Operating System
- Windows 7/10 (32-bit or 64-bit)
